1000mm Forming Width Roof Panel Roll Forming Machine with 45# Steel Shaft and 5.5KW Power for Corrugated Sheet Forming

Product Description:

The Roof Panel Roll Forming Machine is a highly efficient and reliable industrial solution designed specifically for producing high-quality roofing sheets. This machine is ideal for manufacturing IBR sheet forming machine profiles, corrugated sheet forming machine profiles, as well as various types of roof sheet forming machine profiles, making it a versatile addition to any roofing materials production line.

One of the standout features of this Roof Panel Roll Forming Machine is its robust construction and advanced engineering. The machine is equipped with 17 to 25 roller stations, which ensures precise and smooth shaping of metal sheets into desired roofing profiles. The multiple roller stations allow for consistent and uniform sheet forming, reducing material waste and enhancing the overall quality of the finished roofing panels. This makes it an excellent choice for manufacturers seeking both efficiency and precision in their production process.

The shaft material used in this machine is 45# steel, known for its high strength, durability, and resistance to wear and tear. This choice of material guarantees the longevity of the machine components, ensuring stable performance even under continuous operation. The 45# steel shafts contribute to the machine’s ability to handle heavy-duty forming tasks without compromising accuracy or speed.

Powering the Roof Panel Roll Forming Machine is a 5.5KW motor, which provides sufficient energy to drive the roller stations smoothly and efficiently. This power rating strikes a balance between energy consumption and operational output, making the machine both cost-effective and capable of maintaining a steady production pace. Whether producing IBR sheets or corrugated roof panels, this machine’s motor ensures reliable performance and minimal downtime.

The frame of the machine is constructed from H Beam material, which offers exceptional stability and strength. The H Beam frame supports the entire roll forming process, maintaining alignment and reducing vibrations during operation. This sturdy frame design not only extends the lifespan of the machine but also contributes to the consistent quality of the roofing sheets produced. The robust frame is essential for handling the mechanical stresses involved in shaping metal sheets into complex roof profiles.

In terms of dimensions, the Roof Panel Roll Forming Machine measures 7000mm in length, 1500mm in width, and 1400mm in height. These compact dimensions make it suitable for installation in a variety of manufacturing environments, from small workshops to large industrial facilities. Despite its relatively moderate size, the machine is capable of producing roofing sheets swiftly and with high precision, making it a space-efficient solution for roofing sheet production.

Overall, this Roof Panel Roll Forming Machine is a comprehensive solution for manufacturers looking to produce a range of roofing sheet profiles, including IBR sheets and corrugated sheets. Its combination of multiple roller stations, durable 45# steel shafts, powerful 5.5KW motor, and a strong H Beam frame ensures high productivity, durability, and consistent product quality. Whether your business focuses on supplying roofing materials for residential, commercial, or industrial projects, this machine offers the reliability and performance needed to meet your production demands.

Investing in this Roof Panel Roll Forming Machine means gaining a highly adaptable and efficient piece of equipment that can significantly enhance your manufacturing capabilities. Its advanced design and quality construction make it an essential asset for any roofing sheet forming operation, delivering excellent results and long-term value.

Features:

• Product Name: Roof Panel Roll Forming Machine
• Voltage: 380V/50HZ/3Phase
• Machine Size: 7000*1500*1400mm
• Machine Weight: About 5T
• Roller Stations: 17-25 Stations
• Efficient roof sheet panel forming machine suitable for various roofing applications
• Durable corrugated sheet forming machine designed for long-term use
• High precision roof sheet panel forming machine ensuring uniform panel quality
• Stable operation with multiple roller stations for consistent sheet forming

Technical Parameters:

Applications:

The Bluesteel Roof Panel Roll Forming Machine, model BL-3, is an advanced and efficient roof sheet forming machine designed to meet the diverse needs of modern construction and manufacturing industries. Originating from China, this machine operates on a 380V/50HZ/3Phase power supply, ensuring stable and reliable performance suitable for large-scale production environments. Its robust design incorporates 17-25 roller stations, which allows for precise shaping and high-quality output of roofing panels. With a forming width of 1000mm and a forming speed ranging from 10 to 25 meters per minute, the BL-3 model delivers exceptional productivity and efficiency.

This roof sheet forming machine is widely used in various application occasions such as industrial building construction, residential housing projects, agricultural structures, and commercial facilities. It is ideal for manufacturers specializing in corrugated sheets, metal roofing, and wall panels. The versatility of the Bluesteel BL-3 enables it to produce a variety of profiles, including corrugated and trapezoidal sheets, making it an indispensable tool for companies aiming to provide customized roofing solutions.

In scenarios where durability, weather resistance, and aesthetic appeal are crucial, the Bluesteel roof sheet forming machine excels by producing consistent and high-quality panels that meet stringent industry standards. The incorporation of an Omron encoder ensures precise control over the forming process, minimizing material waste and enhancing product accuracy. This makes the BL-3 model particularly suitable for high-volume production lines where efficiency and quality cannot be compromised.

Furthermore, this corrugated sheet forming machine is well-suited for use in regions with rapid urban development and infrastructure expansion, where the demand for durable and cost-effective roofing materials is high. It is also beneficial for retrofit projects, renovations, and prefabricated building manufacturing, providing flexibility in application and ease of integration with other production equipment.

Overall, the Bluesteel Roof Panel Roll Forming Machine BL-3 is an excellent investment for businesses seeking a reliable, high-speed, and precise roof sheet forming machine. Its combination of advanced features, including multiple roller stations, a wide forming width, and a powerful motor system, makes it a cornerstone piece of equipment in the roofing and construction materials industry.

Customization:

Our Bluesteel BL-3 roof sheet panel forming machine offers exceptional customization services to meet your specific production needs. Manufactured in CHINA, this corrugated sheet forming machine is designed with high-quality 45# steel rollers, ensuring durability and precise forming performance.

The BL-3 model features a forming speed ranging from 10 to 25 meters per minute, allowing for efficient and continuous production of roof panels. It can accommodate forming thicknesses between 0.3mm and 0.8mm, providing versatility for various roofing materials.

Constructed with a sturdy H Beam frame, the machine measures 7000*1500*1400mm, ensuring stability and longevity during operation. Whether you require specific panel dimensions or particular roll profiles, our roof sheet panel forming machine can be customized accordingly to suit your project requirements.

Choose the Bluesteel roof sheet panel forming machine for reliable performance, robust construction, and tailored customization options to optimize your roofing panel production.
