5.5KW PLC Control System Customized Shutter Door Machine For Industrial

I'm Online Chat Now

5.5KW PLC Control System Customized Shutter Door Machine For Industrial

5.5KW PLC Control System Customized Shutter Door Machine For Industrial
5.5KW PLC Control System Customized Shutter Door Machine For Industrial
5.5KW PLC Control System Customized Shutter Door Machine For Industrial 5.5KW PLC Control System Customized Shutter Door Machine For Industrial 5.5KW PLC Control System Customized Shutter Door Machine For Industrial

Large Image :  5.5KW PLC Control System Customized Shutter Door Machine For Industrial

Product Details:
Place of Origin: China
Brand Name: Bluesteel
Model Number: BL-PU foam shutter door
Payment & Shipping Terms:
Delivery Time: 60days
Payment Terms: T/T
Supply Ability: 10set

5.5KW PLC Control System Customized Shutter Door Machine For Industrial

Description
Motor: AC Motor Speed: 10-20m/min
Warranty: 1 Year Size: Customized
Operation Mode: Automatic Reducer: Helical Gear Reducer
Application: Industrial Control System: PLC
High Light:

Industrial Shutter Door Machine

,

5.5KW Shutter Door Machine

,

PLC Roller Door Roll Forming Machine

Product Description:

For those looking for a reliable solution to producing insulated slat Rolling shutters, the 39mm and 45mm Windows Shutters Insulated Slat Roll Forming Machine is a great option. It is designed to produce high-quality insulated slat Rolling shutters that have excellent durability and strength.

The 39mm and 45mm Windows Shutters Insulated Slat Roll Forming Machine makes use of precise rollforming technology, and is able to produce tight-knit insulated Rolling shutters of various thicknesses, shapes, and sizes. It can even produce large scale roll forming shutters with ease. In addition, its intuitive controls allow for easy and accurate customization of the shutter, making it easy to meet specific demands and requirements.

The machine has a strong and durable construction, making it suitable for long-term use in harsh conditions. It also has a great safety system, which ensures that production operations are safe and secure. The 39mm and 45mm Windows Shutters Insulated Slat Roll Forming Machine is a great choice for anyone looking for a reliable roll forming solution.



Features:

The PU Foam Shutters Door Roll Forming Machine is an ideal choice for producing panel doors. It has an adjustable forming speed of 40-50m per minute. It is available in 55mm, 77mm and 98mm widths for meeting different application requirements. Its height adjustment range is from 60mm to 200mm for the finished product.

The PU Foam Shutters Door Roll Forming Machine adopts PLC control technology, which makes the operation simple and convenient. It is equipped with universal wheel gear for easy movement and powerful motor for automatic bending. It uses high quality materials to ensure a long service life. It is also equipped with an independent positioning device to ensure accurate product positioning.

In addition, the PU Foam Shutters Door Roll Forming Machine is designed with an automatic batching system for different specifications of shutter doors to ensure accuracy and uniformity. The safety steps have been added to avoid any potential danger and trouble. Its low noise design guarantees a pleasant and comfortable working environment.



Technical Parameters:

Main specification

1. Decoiler: Manual un-coiling Capacity is less than or equal to 3T.

2. Main datas of forming machine: With about 36 stands, roller material is GCr15, model steel, HRC50-54, and the axial diameter is Φ40mm. Main axial material is No 45 steel HRB260-280. Driving part adopted gear box transmission with frequency conversion decelerating; control by PLC for fix length control, accuracy is TEMP±0.5mm, main components are Schneider. Main roll forming machine motor (380V, 50HZ, 11kw) can be adjusted according to the TEMPrequirements.

3. Foaming machine: 1 set (China top brand).

4. Pneumatic flying punching machine 1 set, material of cut is Cr12Mov with Quench: HRC58-62.

5. Automatic punching device 1 set.

6. Finished products table: 1 set.



Applications:

Roller Shutter Door

A roller shutter door is a type of door or window consisting of many horizontal strips. When opened, the door is raised and when closed, it is lowered. In cases of larger doors, the action may be motorized. Apart from providing protection against wind and rain, they are also used as a protective layer against vandalism and burglary attempts.

Roller shutters doors have many applications, such as for vans, garages, kitchens, schools, prisons and warehouses. They are considered as a great method of insulation, and in some parts of the world, local governments subsidize them due to the security benefits they provide. In areas that are subject to inclement weather, roller shutters doors can keep windows safe from hail damage.



Customization:

Roller Shutter Door Machine

Brand Name: Bluesteel

Model Number: BL-PU foam shutter door

Place of Origin: China

Delivery Time: 60days

Payment Terms: T/T

Supply Ability: 10set

Reducer: Helical Gear Reducer

Power: 5.5KW

Speed: 10-20m/min

Motor: AC Motor

Material: Steel & Aluminium

Roller shutter door machines are perfect for residential and commercial applications. Our roller shutter door machines are designed to be robust, reliable and easy to install. The machines are made from steel and aluminium and can be equipped with a helical gear reducer and a 5.5KW AC Motor. The speed of the machine is adjustable from 10-20m/min, allowing for a wide range of applications.



Support and Services:

Roller Shutter Door Machine Technical Support and Services

We provide comprehensive technical support and services for our Roller Shutter Door Machine products. Our team of experienced engineers can help you with installation, maintenance, and repairs. We also offer a 24-hour hotline for emergency services and free online tutorials to help you get the most out of your Roller Shutter Door Machine.

We pride ourselves on our customer service and satisfaction. If you ever have a question or concern about your Roller Shutter Door Machine, please don't hesitate to contact us. We are here to help.
