|Control System:||PLC||Material:||Steel & Aluminium|
|Safety Device:||Photoelectric Sensor||Motor:||AC Motor|
Automatic Roller Shutter Door Making Machine,
10m/Min Roller Door Roll Forming Machine
39mm and 45mm Windows Shutters Insulated Slat Roll Forming Machine has become an essential product in modern manufacture. It is a kind of high-efficiency, energy-saving and multi-functional production equipment. This machine enables to roll-forming metal sheets with different specifications into insulated or non-insulated shutters panel with a uniform cross-sectional shape.
It can be applied to produce a variety of metal sheets, such as Aluminum, Stainless Steel, Galvanized Steel, Copper, Brass and so on. It is equipped with a wide range of features such as adjustable speed, stepless speed regulation and automatic pressing. Therefore, it can automatically form a variety of complex shapes according to customer's needs, such as C-shaped, U-shaped, M-shaped and P-shaped.
It has advantages of high production efficiency, low noise, no pollution, easy operation and maintenance. The machine adopts advanced technologies for automatic control, which guarantees the high precision and good stability of the roll forming machine. The machine can also be customized according to customer's requirements.
All in all, 39mm and 45mm Windows Shutters Insulated Slat Roll Forming Machine is an excellent choice for modern manufacturing. It is ideal for mass production, with its high precision and efficiency. The machine is suitable for a wide range of applications and can meet different manufacturing needs.
The 55mm 77mm 98mm PU Foam Shutters Door Roll Forming Machine is a useful piece of equipment. It is specialized in manufacturing PU foam shutters door roll forming machine. The machine comes with a range of widths from 55mm to 98mm, offering an option to meet different demands of customers. It could complete quick and precise door forming process with one time of material. The material is composed of stiffness stabilizer, high-density foam and auto-adhesives. In addition, its full automatic control system ensures high-speed production, high precision and stable quality. This machine is ideal for any industry that demands stable and high-precision production.
1. Decoiler Manual un-coiling Capacity: ≤3 T
2. Main datas of forming machine
Forming stands: about 36 stands
Roller material GCr15: model steel, HRC50-54
Axial diameter: Φ40mm
Main axial material: No 45 steel HRB260-280
Driving part is gear box transmission
Frequency conversion decelerating
PLC control: fix length control ±1mm
Main components: Schneider
The precision of roller: less than ±0.5mm
Main roll forming machine motor: 380V, 50HZ, 11kw (or according to your requirements)
Machine basement material: H beam
3. Foaming machine: 1 set (China top brand)
4. Pneumatic flying punching machine 1 set
Material of cut: Cr12Mov
5. Automatic punching device 1 set
6. Finished products table: 1 set
A Roller shutter door is a door or window made up of multiple horizontal strips. It is easy to operate, simply raise the door to open it and lower it to close it. Automatic motors are used for large doors. In addition to protection against wind and rain, it also serves as an efficient protection against vandalism and burglary attempts.
Roller shutter door has a wide range of applications, such as being used in residential houses, vans, garages kitchens, schools, prisons, and warehouses. In some areas, local governments even subsidize them due to its security advantage it gives. For regions that are often subjected to inclement weather, they offer a layer of insulation and guard windows against hail.
Bluesteel roller shutter door machine is designed for forming roller shutters used in industrial applications. The machine is equipped with an advanced PLC control system to ensure precision and accuracy. It also comes with a photoelectric sensor for enhanced safety. This machine is powered by an AC motor and comes with a 1-year warranty. Order now and get your Roller Shutter Door Machine delivered in 60 days!
At Roller Shutter Door Machine, we provide the highest level of technical support and service for our customers. Our team of experienced technicians can provide on-site repairs and maintenance services to ensure that your Roller Shutter Door Machine is running optimally. We also offer remote technical support services to provide you with quick and efficient resolutions to any problems.
Our team is available 24/7 to answer any questions you may have and provide additional support. We also offer scheduled maintenance services to ensure that your Roller Shutter Door Machine remains in top condition. We use only the highest quality parts and materials to ensure that your machine is running safely and efficiently.
In addition to our technical support and service, we also offer an extensive selection of replacement parts to keep your Roller Shutter Door Machine running. Our selection includes motors, controllers, and other components that can be used to replace any malfunctioning parts. We also offer training and installation services to ensure that your machine is safely and correctly installed.
At Roller Shutter Door Machine, we are committed to providing the highest quality of technical support and service for our customers. If you have any questions or concerns, please do not hesitate to contact us. Our team is here to help you get the most out of your Roller Shutter Door Machine.
