Product Details:
|
| Thickness Range: | 0.3-0.7mm | Material Stress: | 235MPa 345MPa And 550MPa. |
|---|---|---|---|
| Roller Material: | No.45steel | System: | PLC Control Automatic System |
| Shaft Diameter: | 70mm | Usage: | Steel Structure |
| Roller Station: | As Your Drawing | Machine Structure: | Steel Plate Structure |
| Highlight: | High Speed Stud Roll Former,Hydraulic Stud Roll Former,Metal Stud Roll Former |
||
1. One 40ft container for loading one set machine with manual decoiler;
2. The whole Wiped Anti Rust Oil, PLC controller covered by foam film;
3. Spare parts and some small parts packed in plastic tooling box;
4. All Components Fixed by steel wire with Container.
Technical data of metal roof tile roll forming machine
|
Suitable material |
color steel sheet;0.3-07mm, |
|
Working speed |
about10-25m/min |
|
stress |
235MPa,345MPa,550MPa. |
|
Power |
Main motor power: 5.5 Kw(Depend on final design) |
|
Hydraulic station power: 4Kw(Depend on final design) |
|
|
Material of forming rollers |
No.45 steel, plated with chrome on surface. |
|
Material of cutter,pressing die |
Cr12 mould steel with quench treatment, HRC58-60 |
|
Material of shaft |
High quality 45# steel, Roller grinder milling. |
|
Shaft diameter |
72mm |
|
Controlling system |
Mitsubishi PLC & converter |
|
Total weight of machine |
About 9500KGS |
|
Machine’s size |
about 18m×1.8m× 1.5m (Depend on final design) |
Layout drawing of machine
Our Roll Forming Machine’s advantages
1. Anti-rust roller: CNC machine tooled, Plated with 0.05mm hard chrome .to protect surface shiniing and strong
2. Heat treatment: Heat treatment for cutting frame to remove the steel stress, to avoid deformation.and hardness 60 degree.
3. Cutter blade: Cr12 mould steel with quenched treatment, long life time.
4. High precision: shafts for rollers are tooled by grinding machine. Rollers are CNC processed to ensure precision performance.
5 .automatic PLC : introduced Mitsubishi PLC with touch screen ,inverter,transformer.
6. powerful driving system: big inch train,or gear box driving system.
6. Excellent services: Technician can be sent to your factory to install the machine and train your workers. Lifttime services for our machines.
producing process:
We can also customize the products according to customer ' s requirements
