Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy

I'm Online Chat Now

Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy

Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy
Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy
Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy

Large Image :  Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy

Product Details:
Place of Origin: China
Brand Name: bluesteel
Certification: ce
Model Number: bl
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: spare parts in wooden box,other plastic film cover
Delivery Time: 45days
Payment Terms: T/T or L/C
Supply Ability: 50sets /month

Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy

Description
Thickness Range: 0.2-0.35mm Material Stress: 235MPa 345MPa And 550MPa.
Roller Material: No.45steel System: PLC Control Automatic System
Material: Aluminium Coil
Highlight:

Motorized Roller Shutter Door Roll Forming Machine

,

Aluminum Alloy Shutter Roll Forming Machine

Motorized Aluminum Alloy Rolling Shutter Aluminum Roller Shutter Parts

Polyurethane PU Foam Roller Shutter Slat Door Making Machine

PLC Computer Control Low Noise Rolling Shutter Door Roll Forming Equipment With Hydraulic System



Description:



This producing line uses galvanized steel sheet, colored armor plate or aluminum plate as the material plate. The products produced by this machine are bright in colored, against fading, resistant to rust, and be widely used for door and window in shops, working departments, warehouses, and fire partition.



Technical data of roller shutter door roll forming machine



No
Item
Parameter
1
Material thickness
0.25-0.35mm
2
Raw material
aluminum coil plate and colored steel
3
Material of rollers
GCr15 steel
4
Material of main shaft
45# high quality steel,dia:Φ45mm
5
Driving
by 120# gear box
6
Cutting
fly tracking saw cutting
7
Machine Frame
H Beam Steel
8
Working speed
10-15 m/min
9
Dimension
about 35*1.0*1.2
10
Container
40GP*2





Layout drawing of machine





Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy 0





producing process:

install the steel coil on the un-coilerGuidingWarm box(heating)Roll-forming→PU Injection machine — roll forming Warm box(white glue and black glue foaming) Adjusting device Punching device Flying saw cuttingRun out table



machine photo:

Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy 1

Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy 2Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy 3Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy 4Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy 5



Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy 6Motorized Roller Shutter Door Roll Forming Machine Aluminum Alloy 7



We can also customize the products according to customer ' s requirements





Our Services

1. Installation and training:


a.If buyers visit our factory and check the machine, we will teach you how to install and

use the

machine, and also train your workers/technician face to face.
b.Without visiting, we will send you user manual and video to teach you to install and operate.
c.If buyer needs our technician to go to your local factory, please arrange board and lodging and

other necessary

things.

2. After Service

a.One year guarantee for whole machine.

b.24 hours technical support by email or calling

c.If there is any problem found of the machine, we will repair it for free in one year.
