Hydraulic Powered Metal Roofing Roll Forming Machine With 3 Groups Rollers

I'm Online Chat Now

Hydraulic Powered Metal Roofing Roll Forming Machine With 3 Groups Rollers

China Hydraulic Powered Metal Roofing Roll Forming Machine With 3 Groups Rollers supplier

Large Image :  Hydraulic Powered Metal Roofing Roll Forming Machine With 3 Groups Rollers

Product Details:

Place of Origin: China
Brand Name: bluesteel
Certification: ce
Model Number: bl

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiable
Packaging Details: spare partsin wooden box,other plastic film cover
Delivery Time: 45days
Payment Terms: T/T or L/C
Supply Ability: 50sets /month
Contact Now
Detailed Product Description
Thickness Range: 0.3-0.7mm Material Stress: 235MPa 345MPa And 550MPa.
Roller Material: No.45steel System: PLC Control Automatic System
Material Thickness: 0.3-0.7mm Cutting Type: Hydraulic Cutting



Automatic Hydraulic Crimping Machine / Corrugated Roofing Sheet Curving Machine





Technical parameter



Material Thickness 0.3-0.7mm
Coil Stress 235/345Mpa
Profile Drawing As your profile drawing
Mold Material CR12 steel
Main Motor 4Kw
Hydraulic Motor 2.2Kw
Control System PLC Control
MOQ 1set
Packaging Main body with bubble plastic package









Our  Roll Forming Machine’s advantages



1.  Anti-rust roller: CNC machine tooled, Plated with 0.05mm hard chrome .to protect surface shiniing and strong



2. Heat treatment: Heat treatment for cutting frame to remove the steel stress, to avoid deformation.and hardness 60 degree.



3. Cutter blade: Cr12 mould steel with quenched treatment, long life time.



4. High precision: shafts for rollers are tooled by grinding machine. Rollers are CNC processed to ensure precision performance.



5 .automatic PLC : introduced Mitsubishi PLC with touch screen ,inverter,transformer.



6. powerful driving system:   big inch train,or gear box driving system.



6. Excellent services: Technician can be sent to your factory to install the machine and train your workers. Lifttime services for our machines.
