High Pressure Punching Metal Door Frame Roll Forming Machine Approved CE

I'm Online Chat Now

High Pressure Punching Metal Door Frame Roll Forming Machine Approved CE

China High Pressure Punching Metal Door Frame Roll Forming Machine Approved CE supplier
High Pressure Punching Metal Door Frame Roll Forming Machine Approved CE supplier High Pressure Punching Metal Door Frame Roll Forming Machine Approved CE supplier High Pressure Punching Metal Door Frame Roll Forming Machine Approved CE supplier

Large Image :  High Pressure Punching Metal Door Frame Roll Forming Machine Approved CE

Product Details:

Place of Origin: China
Brand Name: bluesteel
Certification: ce
Model Number: door frame roll forming machine

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiable
Packaging Details: spare partsin wooden box,other plastic film cover
Delivery Time: 45days
Payment Terms: T/T or L/C
Supply Ability: 50sets /month
Contact Now
Detailed Product Description
Thickness Range: 0.8-1.5mm Material Stress: 235MPa 345MPa
Roller Material: No.45steel System: PLC Control Automatic System

high pressure punching ,servo feeding,automatic PLC control cable tray roll forming machine





Specifications:



Place of Origin:

Zhejiang China

 (Mainland)

Brand Name:

bluesteel

Model Number:

Bl door frame

After-sales Service

 Provided:

Engineers available

to service machinery

overseas

Certificate:

BV, SONCAP,

CE Standard

Warranty:

15 Months from

Loading

Name:

roof roll forming

 machine

Operation Worker:

One

Production

Speed:

25m/min standard

Production

Capacity/8hours:

12000m, 50Ton Steel

Production Panel

 Shape:

Custom

Machine Color:

Blue/yellow

Total Power:

About 16KW

Total Installation

Size:

About

25 X 3 X 1.8









Description: steel door frame roll forming machine



BLFM series modular tile sheet roll forming machine consists of uncoiler and its base, infeed guides, film cover

system,fixed position driven forming stations, unching system,shearing device, hydraulic station, PLC control

console and so on. and etc. We can design different profile as per customers' requirements.

Fashionable design  BLFM.





Applications: cable tray





Competitive Advantage:

1), Q: Do you have after sales support?

A: Yes, we are happy to give advice and we also have skilled technicians available across the world. We

need your machines running in order to keep your business running.

2), Q: How do your machines compare with other big companies in this market?

A: We are up to date with the latest technology and improve our machines accordingly

3), Q: How does your factory do regarding quality control?
A: Quality is priority.bluesteel People always attach great importance to quality control from the very

beginning to the end of the production.  Every product will be fully assembled and carefully tested before

it's packed for shipment.

4), Q: Do you sell only standard machines?

A: No, most of our machines are built according to customers specifications, using top brand name



High Pressure Punching Metal Door Frame Roll Forming Machine Approved CE

High Pressure Punching Metal Door Frame Roll Forming Machine Approved CE

High Pressure Punching Metal Door Frame Roll Forming Machine Approved CE

High Pressure Punching Metal Door Frame Roll Forming Machine Approved CE

High Pressure Punching Metal Door Frame Roll Forming Machine Approved CE

High Pressure Punching Metal Door Frame Roll Forming Machine Approved CE

High Pressure Punching Metal Door Frame Roll Forming Machine Approved CE
