Hydraulic Stud And Track Roll Forming Machine For Cutting Aluminum Panel

I'm Online Chat Now

Hydraulic Stud And Track Roll Forming Machine For Cutting Aluminum Panel

China Hydraulic Stud And Track Roll Forming Machine For Cutting Aluminum Panel supplier

Large Image :  Hydraulic Stud And Track Roll Forming Machine For Cutting Aluminum Panel

Product Details:

Place of Origin: China
Brand Name: bluesteel
Certification: ce
Model Number: bl

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiable
Packaging Details: spare partsin wooden box,other plastic film cover
Delivery Time: 45days
Payment Terms: T/T or L/C
Supply Ability: 50sets /month
Detailed Product Description
Thickness Range: 0.3-0.7mm Material Stress: 235MPa 345MPa And 550MPa.
Roller Material: No.45steel System: PLC Control Automatic System

Hydraulic Cutting Aluminum sheet Metal Stud And Track Roll Forming Machine From Hangzhou



Technical data of metal roof tile roll forming machine

Suitable material

 color steel sheet;0.3-07mm,

Working speed

about10-25m/min

stress

235MPa,345MPa,550MPa.

Power

Main motor power: 5.5 Kw(Depend on final design)

Hydraulic station power: 4Kw(Depend on final design)

Material of forming rollers

No.45 steel, plated with chrome on surface.

Material of cutter,pressing die

Cr12 mould steel with quench treatment, HRC58-60

Material of shaft

High quality 45# steel, Roller grinder milling.

Shaft diameter

72mm

Controlling system

Mitsubishi PLC & converter

Total weight of machine

About 9500KGS

Machine’s size

about 18m×1.8m× 1.5m (Depend on final design)





Layout drawing of machine



Hydraulic Stud And Track Roll Forming Machine For Cutting Aluminum Panel





Our  Roll Forming Machine’s advantages



1. Anti-rust roller: CNC machine tooled, Plated with 0.05mm hard chrome .to protect surface shiniing and strong



2. Heat treatment: Heat treatment for cutting frame to remove the steel stress, to avoid deformation.and hardness 60 degree.



3. Cutter blade: Cr12 mould steel with quenched treatment, long life time.



4. High precision: shafts for rollers are tooled by grinding machine. Rollers are CNC processed to ensure precision performance.



5 .automatic PLC : introduced Mitsubishi PLC with touch screen ,inverter,transformer.



6. powerful driving system:   big inch train,or gear box driving system.



6. Excellent services: Technician can be sent to your factory to install the machine and train your workers. Lifttime services for our machines.



producing process:





Hydraulic Stud And Track Roll Forming Machine For Cutting Aluminum Panel





We can also customize the products according to customer ' s requirements



Packaging Detail of stud and track roll forming machine :

1. One 40ft container for loading one set machine with manual decoiler;
2. The whole Wiped Anti Rust Oil, PLC controller covered by foam film;
3. Spare parts and some small parts packed in plastic tooling box;
4. All Components Fixed by steel wire with Container.
